Ortofon SPU Royal G MK II Moving Coil Cartridge and Headshell

Ortofon SPU Royal GM Cartridge

The Ortofon SPU Royal GM represents one of the most refined expressions of the classic SPU design, combining traditional analogue character with advanced stylus and coil technology. It delivers an open, highly detailed sound with exceptional clarity while maintaining the rich, musical presentation that defines the SPU range.

At its core is Ortofon’s Replicant 100 stylus, featuring a reduced tip mass for superior groove contact and enhanced high-frequency performance. This allows the cartridge to extract fine detail and subtle nuances from recordings with remarkable precision.

The use of Electrum coils—a gold and silver alloy—ensures highly accurate and uncoloured signal transmission, while a carefully optimised damping system reduces tracking force requirements and improves linearity across the frequency range. High-purity 6N copper wiring further preserves microdynamic detail, resulting in a natural and highly resolving listening experience.

Key Features:

• Classic SPU design with integrated headshell (GM type)

• Replicant 100 stylus for exceptional detail and accuracy

• Reduced tip mass for improved high-frequency response

• Electrum (gold/silver alloy) coils for precise signal transmission

• High-purity 6N copper wiring for enhanced microdynamics

• Optimised damping system for improved linearity and tracking

Technical Specifications:

• Output Voltage: 0.2 mV (at 1kHz, 5cm/sec)

• Channel Balance: < 1 dB (at 1kHz)

• Channel Separation: > 25 dB (1kHz), > 20 dB (15kHz)

• Frequency Response: 20 Hz – 20 kHz (+1.5/-0 dB)

• Tracking Ability: > 70 µm (at 315Hz)

• Compliance (Dynamic, Lateral): 8 µm/mN

• Stylus Type: Nude Ortofon Replicant 100

• Stylus Radius: 5 / 100 µm

• Tracking Force Range: 2.5 – 3.5 g

• Recommended Tracking Force: 3.0 g

• Tracking Angle: 20°

• Internal Impedance: 7Ω

• Recommended Load Impedance: > 100Ω

Build & Design:

• Cartridge Body: Grinded Wood

• Coil Wire: Gold-plated silver (Electrum)

• Colour: Shiny Black

• Weight: 30 g

What’s Included:

• Ortofon SPU Royal GM Cartridge (integrated headshell)

• Documentation

Note: This product is available for in-store demonstration. Visit the Spinning Room showroom in Leeds to experience the SPU Royal GM in person.
