Ortofon MC Diamond Moving coil phono cartridge (free fitting)

Ortofon MC Diamond Moving Coil Cartridge

The Ortofon MC Diamond represents the absolute pinnacle of Ortofon’s cartridge engineering, designed to deliver the highest level of accuracy, detail, and musical realism. As part of Ortofon’s flagship range, it pushes analogue reproduction to its limits with cutting-edge materials and advanced design.

At the heart of the MC Diamond is a Diamond cantilever paired with the renowned Replicant 100 diamond stylus. This combination offers exceptional speed, precision, and responsiveness, allowing the cartridge to extract the finest detail from the record groove. The result is an extraordinarily transparent and lifelike presentation, with outstanding clarity across both micro and macro dynamics.

The cartridge body is constructed using Ortofon’s Selective Laser Melting (SLM) Titanium process, where fine titanium particles are fused layer by layer into a single, rigid structure. This approach eliminates unnecessary material while providing extremely high internal damping, resulting in near-total freedom from unwanted resonance.

Further refinement comes from the re-engineered Wide Range Damping (WRD) system, incorporating an advanced rubber suspension developed with Multi Wall Carbon Nanotube (MWCNT) technology. This ensures optimal control of movement, improved tracking stability, and minimal distortion. Additional damping is provided by a Thermo-Plastic Elastomer (TPE) base, further enhancing overall performance.

The MC Diamond delivers a perfectly balanced sound, combining precision, speed, and openness with natural tonality and texture. It is designed to integrate seamlessly with high-end tonearms and phono stages, offering uncompromised performance for the most demanding systems.

Key Features:

• Flagship Ortofon moving coil cartridge

• Diamond cantilever for ultimate precision and responsiveness

• Nude Ortofon Replicant 100 stylus for maximum detail retrieval

• SLM Titanium body for exceptional rigidity and damping

• Wide Range Damping (WRD) system with advanced suspension

• Multi Wall Carbon Nanotube (MWCNT) enhanced rubber compound

• TPE base for additional resonance control

• Outstanding transparency, speed, and dynamic accuracy

• Compatible with high-end tonearms and phono systems

Technical Specifications:

• Output Voltage: 0.2 mV

• Channel Balance: 0.5 dB

• Channel Separation: 25 dB (1 kHz), 20 dB (15 kHz)

• Frequency Response: 20 Hz – 20 kHz (±2 dB)

• Tracking Ability: 80 μm

• Compliance: 11 μm

• Stylus Type: Nude Ortofon Replicant 100

• Tracking Force Range: 2.5 – 2.8 g

• Recommended Tracking Force: 2.6 g

• Tracking Angle: 23°

• Internal Impedance: 6 Ω

• Cantilever Material: Diamond

• Recommended Load Impedance: > 10 Ω

• Cartridge Weight: 17.5 g

Build & Design:

• Body Material: SLM Titanium

• Damping System: Wide Range Damping (WRD)

• Suspension: MWCNT-enhanced rubber compound

• Base Material: Thermo-Plastic Elastomer (TPE)

What’s Included:

• Ortofon MC Diamond Cartridge

• Mounting hardware

• Documentation

Note: This product is available for in-store demonstration. Visit the Spinning Room showroom in Leeds to experience the MC Diamond in person.
